HMI Weintek cMT3102X cMT3102X, Display. Display. 10.1” TFT. Resolution. 1024 x 600. Brightness (cd/m2). 350. Contrast Ratio. 500:1. Backlight Type. LED. Backlight Life Time

cMT3102X, Display. Display. 10.1” TFT. Resolution. 1024 x 600. Brightness (cd/m2). 350. Contrast Ratio. 500:1. Backlight Type. LED. Backlight Life Time

cMT3102X

แบรนด์ : WEINTEK สินค้า HMI ซีรีย์ : cMT X Series

เอกสาร

THB0.00

จัดส่งภายใน 2–5 วัน

รายละเอียดสินค้า
ข้อมูลสินค้า
แค็ตตาล็อก

รายละเอียดสินค้า

 10.1" 1024 x 600 TFT LCD, LED Backlight
 Built- in 4GB Flash Memory and RTC
 COM2 and COM3 RS-485 support MPI 187.5K, please use one at a time.
 CAN Bus Supports CANopen, CAN Bus 2.0A/2.0B and SAE J1939
 Fan-less Cooling System
 PCB coating process ensures high reliability to resist from corrosion in harsh environment.
 Built-in Power Isolation
 NEMA4 / IP66 Compliant Front Panel
 Compatible with M02 WiFi Expansion Module that supports wireless communication.

WEINTEK cMT3102X cMTX Series Advanced HMI, Screen Size 10.1", Resolution 1024 x 600, Rating UL 4X (Indoor), NEMA 4, IP66, CPU RAM Flash 1.6GHz 1GB / 4GB, Voltage 24VDC +/- 20%
