Hollow 8mm,1000P/R,5-30VDC,NPN/PNP
TRD-NH1000-RZ
-
รายละเอียดสินค้า
TRD-NH1000-RZ |
|
| Encoder Type | Incremental |
| Duty Type | Medium |
| Pulse Per Revolution | 1000 |
| Input Voltage (VDC) | 5-30 |
| Output Form | Push-Pull (Totem Pole) |
| Signal Format | Quadrature (2-Phase Output) + Home Position |
| Output From | Side |
| Shaft | Hollow |
| Shaft Diameter (mm) | 8 |
| Diameter (mm) | 50 |
| Depth (mm) | 35 |
| Mounting Pitch (mm) | 60 |
| Cable Length (meter) | 0.50 |
| Connector Type | Tinned Ends |
| Protection Level | IP50 (Dust Proof) |
| Short Circuit Protection | No |
| Reverse Origin Action | Positive Logic (Active High) |
| Total Shaft Length (mm) | 8.0 |
| Usable Shaft Length (mm) | 8.0 |
