Covered type, 100 to 240 VAC, Power rating 30 W, Output: 12 V, Terminal blocks (Screw terminal), Undervoltage alarm output, Parallel operation, Harmonic current emissions
S8TS-03012-E1
เอกสาร
THB0.00
รายละเอียดสินค้า
Specifications
| Type | Modular |
| Mounting method | DIN rail |
| Phase | Single |
| Power output | 30 W |
| Efficiency | 70 % |
| Output voltage | 12 V |
| Rated output current | 2.5 A |
| Temperature range | -25-65 °C |
| Terminal | Screw |
| Communication port(s) | None |
| Alarm function | - |
| Number of output branches | 1 |
| Rated supply voltage at AC 50 Hz | 100-240 V |
| Allowable supply voltage AC | 85-264 V |
| Width | 43 mm |
| Height | 120 mm |
| Depth | 120 mm |
