Functional Specifications
|
Display Type
|
TFT Color LCD
|
|---|---|
|
Display Size
|
5.7"
|
|
Resolution
|
640 x 480 Pixels (VGA)
|
|
Dot pitch
|
W0.18 x H0.18mm [W0.01 X H0
|
|
Effective Display Area
|
115.2 x 86.4mm (4.54 x 3.4in)
|
|
Display Colors
|
65,536 Colors (No blink) / 16,384 Colors (Blink)
|
|
Backlight
|
White LED (Not user replaceable. When replacement is required, contact your local distributor.)
|
|
Brightness Control
|
16 Levels (Adjusted with touch panel)
|
|
Contrast Control
|
Not Applicable
|
|
Language Fonts
|
Japanese: 6,962 (JIS Standards 1 & 2) (including 607 non-kanji characters), ANK: 158 (Korean fonts, Simplified Chinese and Traditional Chinese fonts are downloadable.
|
|
Character Sizes
|
Standard Font: 8 x 8, 8 x 16, 16 x 16 and 32 x 32 Pixel Fonts, Stroke Font: 6 to 127 Pixel Fonts, Stroke Font: 6 to 127 Pixel Fonts
|
|
Font Sizes
|
Standard font: Width can be expanded up to 8 times., Height can be expanded up to 8 times.*1
|
|
8 x 16 dots
|
80 Char. x 30 Rows
|
|
16 x 16 dots
|
40 Char. x 30 Rows
|
|
32 x 32 dots
|
20 Char. x 15 Rows
|
|
8 x 8 dots
|
80 Char. x 60 Rows
|
|
Application Memory
|
Flash EPROM 32MB*2
|
|
Data Backup
|
SRAM 320KB*3
|
|
Clock Accuracy
|
±65 sec./month (deviation at room temperature and power is OFF)*4
|
|
Touch Panel Type
|
Resistive Film (Analog)
|
|
Touch Panel Resolution
|
1,024 x 1,024
|
|
Touch Panel Service Life
|
1 million times or more
|
|
Serial (COM1)
|
Asynchronous Transmission:
RS-232C/RS-422/RS-485, Data Length: 7 or 8 bits Stop Bit: 1 or 2 bits Parity: None, odd, or even, Data transmission speed: 2,400 to 115,200bps, 187,500bps (MPI) Maximum Communication Distance*5: When using RS-232C: 15m (49.2ft) When using RS-422 at 115,200bps : 1,200m (3937ft)*5 |
|
Ethernet (LAN)
|
IEEE802.3i/IEEE802.3u, 10BASE-T/100BASE-TX Connector: Modular Jack (RJ-45) x 1 Maximum Communication Distance*5: 100m (328.1ft)*6
|
|
USB (TYPE-A)
|
Conforms to USB2.0 (TYPE-A) x 1, Power Supply Voltage: DC 5 V ±5 %, Output Current: 500mA or less, Communication Distance: 5m [16.4ft.] or less
|
|
USB (mini-B)
|
Conforms to USB2.0 (mini-B) x 1, Communication Distance: 5m [16.4ft.] or less
|
|
CF Card
|
-
|
|
SD Card
|
SD Card Slot x 1
|
|
Function Switch
|
12 Switches (Right: 6 Switches, Left: 6 Switches) (DOUT: 2 Open Collector Output [F1, F2], Operation Switch: 1 Open Collector Output [O.P])
|
|
Emergency Switch Output
|
Push-lock Switch, 3 Contacts (A-contact: 1 Contact, B-contact: 2 Contacts), Rated Voltage: DC 30V, Maximum Rated Current: 1A, (Minimum Allowable Load: DC 5V, 1mA), Applicable Standards*6: IEC/EN60947-5-1, IEC/EN60947-5-5, UL508, CSA C22.2 No.14*7
|
|
3-Position Enable Switch Output
|
GP Rear Panel Switch, 2 Contacts (A-contact), Rated Voltage: DC 30V, Maximum Rated Current: 700mA (Minimum Allowable Load: DC 3V, 5mA), Applicable Standards*6: IEC/EN60947-5-8, 60204-1, UL508, CSA C22.2 No.14, ISO12100/EN12100-1,2, ISO11161/prEN11161 ISO10218/EN775, ANSI/RIA R15.06, ANSI B11.19*8
|
|
Key Switch Output
|
1c-Contact, Rated Voltage: DC 24V, Maximum Rated Current: 300mA
|
|
Operation Output
|
Open Collector Output: 1 Point, Rated Voltage: DC 24V, Maximum Rated Current: 300mA
|
|
External Buzzer Output
|
Open Collector Output 1 Point, Rated Voltage: DC 24V, Maximum Rated Current: 300mA
|
|
DOUT Output
|
Open Collector Output: 2 Points [F1, F2], Rated Voltage: DC 24V, Maximum Rated Current: 300mA/point
|
2Amount of memory you can use differs depending on your screen editing software. Refer to the manual for your screen editing software.
3Amount of memory you can use differs depending on your screen editing software. Refer to the manual for your screen editing software. Rechargeable lithium battery for backup memory.
4Depending on the operating temperature and age of unit, the clock can deviate from -380 to +90 sec./month. For systems where this level of deviation is a problem, the user should monitor and make adjustments when required.
5When using the Conversion Adapter (model number: AGP3000H-ADPCOM-01), the distance includes the cable length between this product and the Conversion Adapter.
6When using the Conversion Adapter (model number: AGP3000H-ADPCOM-01), the distance includes the cable length between this product and the Conversion Adapter.
7Overall system may not meet these standards if implemented outside these parameters. Follow these standards when designing the system.
8Overall system may not meet these standards if implemented outside these parameters. Follow these standards when designing the system.
General Specifications
|
International Safety Standards
|
|
|---|---|
|
Rated Input Voltage
|
24Vdc
|
|
Input Voltage Limits
|
DC 19.2 to 28.8Vdc
|
|
Allowable Voltage Drop
|
10ms or less
|
|
Power Consumption
|
12W or less (When power is not supplied to external devices: 8W or less)
|
|
In-Rush Current
|
35A or less
|
|
Voltage Endurance
|
500Vac, 20mA for 1 minute (between charging and FG terminals)
|
|
Insulation Resistance
|
500Vdc, 10MΩ or more (between charging and FG terminals)
|
|
Surrounding Air Temperature
|
0 to 40°C (32 to 104°F)
|
|
Storage Temperature
|
-20 to 60°C (-4 to 140°F)
|
|
Ambient Humidity
|
10% to 90% RH (Non Condensing, Wet Bulb Temperature 39°C [102.2°F] or less)
|
|
Storage Humidity
|
|
|
Dust
|
0.1 mg/m3 (10-7 oz/ft3) or less (Non-conductive Levels)
|
|
Pollution Degree
|
For use in pollution degree 2 environment
|
|
Atmosphere
|
Free of corrosive gases
|
|
Air Pressure (altitude range)
|
800 to 1,114hPa (2,000m [6,561ft] or lower)
|
|
Vibration Resistance
|
IEC/EN 61131-2 compliant 5 to 9Hz Single amplitude 3.5mm (0.14in)
9 to 150Hz Fixed acceleration: 9.8m/s2 X, Y, Z directions for 10 cycles (Approximately 100 Minutes) |
|
Concussion Resistance
|
IEC/EN 61131-2 compliant 147m/s2, X, Y, Z directions for 3 times
|
|
Noise Immunity
|
Noise Voltage: 1,000Vp-p
Pulse Duration: 1ms, Rise Time: 1ns (via noise simulator) |
|
Electrostatic Discharge Immunity
|
Contact Discharge Method: 6kV (IEC/EN 61000-4-2 Level 3)
|
|
Drop Resistance
|
IEC 61131-2 Compliant 1.0m [3.3ft] Drop - 2 Times
|
|
Grounding
|
Functional Grounding: Grounding resistance of 100Ω, 2mm2 (AWG 14) or thicker wire, or your country's applicable standard
(same for FG and SG terminals). |
|
Structure
|
Equivalent to IP65*9
|
|
Weight Approx.
|
910g (2.01lb) or less: without a key switch, unit only
960g (2.12lb) or less: with a key switch, unit only |
9This product has been tested using conditions equivalent to the standards shown in the specification.
External Dimensions with Cables
ข้อมูลสินค้า
| GP-4100 Series | GP4104G1D | PFXGP4104G1D | 3.4-inch Compact Type. Interface: Ethernet. Display Colors: Monochrome Green/Red/Orange. Power Supply: DC. |
| GP4104W1D | PFXGP4104W1D | 3.4-inch Compact Type. Interface: Ethernet. Display Colors: Monochrome White/Red/Pink. Power Supply: DC. | |
| GP4105G1D | PFXGP4105G1D | 3.4-inch Compact Type. Interface: RS-232C. Display Colors: Monochrome Green/Red/Orange. Power Supply: DC. | |
| GP4105W1D | PFXGP4105W1D | 3.4-inch Compact Type. Interface: RS-232C. Display Colors: Monochrome White/Red/Pink. Power Supply: DC. | |
| GP4106G1D | PFXGP4106G1D | 3.4-inch Compact Type. Interface: RS-422/485. Display Colors: Monochrome Green/Red/Orange. Power Supply: DC. | |
| GP4106W1D | PFXGP4106W1D | 3.4-inch Compact Type. Interface: RS-422/485. Display Colors: Monochrome White/Red/Pink. Power Supply: DC. | |
| GP4107G1D | PFXGP4107G1D | 3.4-inch Compact Type. Interface: RS-485 (isolation). Display Colors: Monochrome Green/Red/Orange. Power Supply:DC. | |
| GP4107W1D | PFXGP4107W1D | 3.4-inch Compact Type. Interface: RS-485 (isolation). Display Colors: Monochrome White/Red/Pink. Power Supply:DC. | |
| GP-4200 Series | PFXGM4201TAD | 3.5-inch Modular Type. Touch Panel Type: Analog Resistive. Power Supply: DC. | |
| PFXGP4201TADW | 3.5-inch W Model. Touch Panel Type: Analog Resistive. Power Supply: DC. | ||
| PFXGP4201TAD | 3.5-inch Standard Model. Touch Panel Type: Analog Resistive. Power Supply: DC. | ||
| PFXGP4203TAD | 3.5-inch Standard Model. Touch Panel Type: Analog Resistive. Power Supply: DC. Isolated model. | ||
| GP-4300 Series | PFXGM4301TAD | 5.7-inch Modular Type. Touch Panel Type: Analog Resistive. Power Supply: DC. | |
| PFXGP4301TADW | 5.7-inch W Model. Touch Panel Type: Analog Resistive. Power Supply: DC. | ||
| PFXGP4301TADWC | 5.7-inch W Model. Touch Panel Type: Analog Resistive. Power Supply: DC. Coated model. | ||
| PFXGP4301TAD | 5.7-inch Standard Model. Touch Panel Type: Analog Resistive. Power Supply: DC. | ||
| PFXGP4301TADC | 5.7-inch Standard Model. Touch Panel Type: Analog Resistive. Power Supply: DC. Coated model. | ||
| PFXGP4303TAD | 5.7-inch Standard Model. Touch Panel Type: Analog Resistive. Power Supply: DC. Isolated model. | ||
| GP-4400 Series | PFXGP4401WADW | 7.0-inch Wide W Model. Touch Panel Type: Analog Resistive. Power Supply: DC. | |
| PFXGP4401TAD | 7.5-inch Standard Model. Touch Panel Type: Analog Resistive. Power Supply: DC. | ||
| GP-4500 Series | PFXGP4501TADW | 10.4-inch W Model. Touch Panel Type: Analog Resistive. Power Supply: DC. | |
| PFXGP4501TAA | 10.4-inch Standard Model. Touch Panel Type: Analog Resistive. Power Supply: AC. | ||
| PFXGP4501TAAC | 10.4-inch Standard Model. Touch Panel Type: Analog Resistive. Power Supply: AC. Coated model. | ||
| PFXGP4501TAD | 10.4-inch Standard Model. Touch Panel Type: Analog Resistive. Power Supply: DC. | ||
| PFXGP4501TADC | 10.4-inch Standard Model. Touch Panel Type: Analog Resistive. Power Supply: DC. Coated model. | ||
| PFXGP4501TMA | 10.4-inch Standard Model. Touch Panel Type: Matrix Resistive. Power Supply: AC. | ||
| PFXGP4501TMD | 10.4-inch Standard Model. Touch Panel Type: Matrix Resistive. Power Supply: DC. | ||
| PFXGP4503TAD | 10.4-inch Standard Model. Touch Panel Type: Analog Resistive. Power Supply: DC. Isolated model. | ||
| Product Name | Model No. | Global Code | Description |
| GP-4600 Series | PFXGP4601TAA | 12.1-inch Standard Model. Touch Panel Type: Analog Resistive. Power Supply: AC. | |
| PFXGP4601TAAC | 12.1-inch Standard Model. Touch Panel Type: Analog Resistive. Power Supply: AC. Coated model. | ||
| PFXGP4601TAD | 12.1-inch Standard Model. Touch Panel Type: Analog Resistive. Power Supply: DC. | ||
| PFXGP4601TADC | 12.1-inch Standard Model. Touch Panel Type: Analog Resistive. Power Supply: DC. Coated model. | ||
| PFXGP4601TMA | 12.1-inch Standard Model. Touch Panel Type: Matrix Resistive. Power Supply: AC. | ||
| PFXGP4601TMD | 12.1-inch Standard Model. Touch Panel Type: Matrix Resistive. Power Supply: DC. | ||
| PFXGP4603TAD | 12.1-inch Standard Model. Touch Panel Type: Analog Resistive. Power Supply: DC. Isolated model. | ||
| Product Name | Model No. | Global Code | Description | |
| GP-Pro EX V*.* | PFXEXEDV** | HMI Screen editor & Logic Programming Software *1 | ||
| GP-Pro EX Editor License | PFXEXEDLSV** | GP-Pro EX editor license *2 | ||
| Pro-Server EX Developer | PFXEXSDVV** | Software that connects a PC to a GP via Ethernet and collects and transmits data *3*4 |
||
| Pro-Server EX Developer License | EX-SED-LICENSE | PFXEXSDLS | Pro-Server EX developer license *5 | |
| Pro-Server EX Runtime License | EX-SRT-LICENSE | PFXEXSRLS | Pro-Server EX Runtime license *6 | |
| GP-Viewer EX | Single license | EX-VIEWER-LICENSE | PFXEXVW | License allowing a PC to access a HMI in remote mode *3*7 |
| 10 licenses | EX-VIEWER-LICENSE-10 | PFXEXVWLS10 | ||
| 30 licenses | EX-VIEWER-LICENSE-30 | PFXEXVWLS30 | ||
| MES Action License | EX-MES-LICENSE-V** | PFXEXMSLSV** | License key permitting Pro-Server EX to access a database *3 | |
| RPA Client License | Single License | EX-RPA | PFXEXRP | License to access a PC on the network in remote mode *3*8 |
| 10 Licenses | EX-RPA-10 | PFXEXRPLS10 | ||
| 30 Licenses | EX-RPA-30 | PFXEXRPLS30 | ||
| Product Name | Model No. | Global Code | Description | |
| RS-232C Cable | 5m | CA3-CBL232/5M-01 | PFXZC3CBR251 | Cable for RS-232C connection between various hosts and the GP |
| RS-422 Cable (Plug Type) | 5m | CA3-CBL422-01 | PFXZC3CBR452 | Cable for RS-422 connection between various hosts and the GP (Plug Type) |
| RS-422 Cable (Socket Type) | 5m | CA3-CBL422/5M-01 | PFXZC3CBR451 | Cable for RS-422 connection between various hosts and the GP (Socket Type) |
| Mitsubishi PLC A-Series Connection Cable | 5m | CA3-CBLA-01 | PFXZC3CBA51 | Cable for directly connecting an A Series CPU |
| Mitsubishi PLC A-Series Cable | 5m | ZC9CBA51 | PFXZC9CBA51 | Connects the GP directly to the CPU programming port on the Mitsubishi Electric PLC A/ QnA series |
| Mitsubishi PLC Q-Series Connection Cable | 5m | CA3-CBLQ-01 | PFXZC3CBQ51 | Cable for directly connecting a Q Series CPU |
| Mitsubishi PLC Q-Series CPU I/F Cable | 3m | ZC9CBQ31 | PFXZC9CBQ31 | Connects the GP directly to the CPU programming port on the Mitsubishi Electric PLC Q series |
| Mitsubishi PLC Q Series Link Cable | 5m | CA3-CBLLNKMQ-01 | PFXZC3CBQL51 | Cable for directly connecting a Q Series Link Unit |
| Mitsubishi PLC FX-Series Connection Cable | 5m | CA3-CBLFX/5M-01 | PFXZC3CBFX51 | Cable for directly connecting an FX Series CPU |
| 1m | CA3-CBLFX/1M-01 | PFXZC3CBFX11 | ||
| Mitsubishi PLC FX-Series CPU I/F Cable | 1m | ZC9CBFX11 | PFXZC9CBFX11 | Connect the GP directly to the CPU programming port on the Mitsubishi Electric PLC FX series |
| 5m | ZC9CBFX51 | PFXZC9CBFX51 | ||
| Omron PLC SYSMAC Link Cable | 5m | CA3-CBLSYS-01 | PFXZC3CBSYS51 | Cable for directly connecting a SYSMAC Link Unit |
| Panasonic Electric Works PLC FP Series CPU Cable | 2m | ZC9CBFP21 | PFXZC9CBFP21 | Connects the GP directly to the CPU port on the Panasonic Electric Works PLC FP series |
| Siemens TTY Converter Cable | 5m | CA6-CBLTTY/5M-01 | PFXZC6CBTTY51 | Cable for connecting a PLC S5 series to the GP4000 |
| MPI Cable | 3.5m | ST03-A2B-MPI21-PFE *8 | PFXZGPCBMPPE1 | Connects a host controller to the GP for MPI communication. |
| CA3-MPIPG1-PFE *9 | PFXZGPCBMPPE5 | |||
| CA3-MPIPGN-PFE *9 | PFXZGPCBMPPE6 | |||
| Multi-Link Cable | 5m | CA3-CBLMLT-01 | PFXZC3CBML1 | Connects a host controller to the GP for multi-link(n:1) communication |
| PFXZCBCBML1 | Connects a host controller directly to the GP4000 (D-sub 9 pin plug) for multi-link (n:1) communication. |
|||
| RS-232C 9-pin/25-pin Conversion Cable | 20cm | CA3-CBLCBT232-01 | PFXZC3CBCVR21 | Cable for converting a D-Sub 9-pin plug to a D-Sub 25-pin socket |
| RS-422C 9-pin/25-pin Conversion Cable | 20cm | CA3-CBLCBT422-01 | PFXZCBCBCVR41 | Cable for converting a D-Sub 9-pin plug to a D-Sub 25-pin socket |
| 2-port Adapter II | GP070-MD11 | PFXZGPADMD1 | Allows simultaneous use of an GP unit Series unit and a Mitsubishi PLC A, QnA, FX Series peripheral device. |
|
| 2-port Adapter II Cable | 5m | CA3-MDCB11 | PFXZC3CBMD1 | Cable for connecting a 2-port adapter to the GP4000 |
| PFXZCBCBMD1 | Connects Mitsubishi PLC directly to the GP4000 (D-sub 9 pin plug) using 2 port adapter II |
|||
| COM Port Conversion Adapter | CA3-ADPCOM-01 | PFXZC3ADCM1 | For COM 1 Pin conversion adapter for connecting the COM 2-dedicated communication option to the COM 1 port on the GP3000 |
|
| Terminal Block Conversion Adapter | CA3-ADPTRM-01 | PFXZC3ADR41 | Connects output from a GP unit’s Serial Interface (D-sub 9 pin socket) directly with an RS-422 terminal block. |
|
| RS-422 Terminal Block Conversion Adapter | PFXZCBADTM1 | Connects output from a GP unit’s Serial Interface (D-sub 9 pin plug) directly with an RS-422 terminal block. |
||
| RS-232C Isolation Unit | CA3-ISO232-01 | PFXZC3ADISR21 | Unit for connecting various hosts and the GP4000 by insulating | |
*8. Excluding GP-4x03T
*9. GP-4x03T only
| Product Name | Model No. | Global Code | Description | |
| USB Transfer Cable (USB Type A/USB Type A) | 2m | CA3-USBCB-01 | PFXZC3CBUSA1 | Cable for transferring screen data from a PC (USB Type A) to the GP unit (USB Type A) |
| USB Transfer Cable (USB Type A/mini-B) | 1.8m | ZC9USCBMB1 | PFXZC9USCBMB1 | Cable for transferring screen data from a PC (USB Type A) to the GP unit (USB mini-B). |
| USB Panel-mount Extension Cable (USB Type A) | 1m | CA5-USBEXT-01 | PFXZC5CBUBEX1 | Extension cable attaching USB interface to front panel. |
| USB Panel-mount Extension Cable (USB mini-B) | 1m | ZC9USEXMB1 | PFXZC9USEXMB1 | Extension cable that attaches to the USB (mini-B) interface on the front side of the operation panel. |
| USB-Serial (RS-232C) Conversion Cable | 50cm | CA6-USB232-01 | PFXZC6CBCVUSR21 | Cable for converting a GP unit’s USB interface into a serial interface (RS-232C). Allows connection to modema or barcode readers that support RS-232C. |
| USB-Serial (RS-422/485) Conversion Adapter | PFXZCBCBCVUSR41 | Cable for connecting a GP unit (USB Type A) with an external device (RS-422/RS-485) | ||
| SD Memory Card | PFXZCBSD4GC41 | SD Memory Card (4 GB, CLASS4) | ||
| Screen Protection Sheet | For 3.4-inch | ZC9DS31 | PFXZC9DS31 | Disposable, dirt-resistant sheet for the GP unit screen (5 sheets/set) |
| For 3.5-inch | CA6-DFS4-01 | PFXZC6DS41 | ||
| For 5.7-inch | PFXZCBDS61 | |||
| For 7.0-inch Wide | PFXZCBDS72 | |||
| For 7.5-inch | PFXZCBDS71 | |||
| For 10.4-inch | PFXZCBDS101 | |||
| For 12.1-inch | CA7-DFS12-01 | PFXZC7DS121 | ||
| Panel Cutout Adapter | For 10.4-inch | CA4-ATM10-01 | PFXZC4AT101 | Panel cutout adapter for mounting GP-4500 Series in cutout for GP-2500/2600 series. |
| Environment Cover | For 3.5-inch | PFXZCBOP41 | Environmental resistant Cover | |
| For 5.7-inch | PFXZCBOP61 | |||
| For 7.0-inch Wide / 7.5-inch | PFXZCBOP71 | |||
| For 10.4-inch | PFXZCBOP101 | |||
| For 12.1-inch | PFXZCBOP121 | |||
Maintenance Options
Please purchase when the product is damaged or lost.
| Product Name | Model No. | Global Code | Description | |
| 3.4-inch Installation Fastener | ZC9AF31 | PFXZC9AF31 | Used to install the GP into a solid panel (2 pieces/ set) | |
| Installation Fastener | PFXZCBAF1 | Used to install the GP into a solid panel (4 pieces/ set) | ||
| 3.4-inch Installation Gasket | ZC9WG31 | PFXZC9WG31 | Provides dust and moisture resistance when GP is installed into a solid panel (1 piece) | |
| 3.5-inch Installation Gasket | PFXZCBWG41 | |||
| 5.7-inch Installation Gasket | PFXZCBWG61 | |||
| 7.5-inch & 7.0-inch Wide Installation Gasket | PFXZCBWG71 | |||
| 10.4-inch T models Installation Gasket | PFXZCBWG101 | |||
| 12.1-inch & 10.4-inch TW models Installation Gasket | PFXZCBWG121 | |||
| USB Clamp Type A (1 port) | For 3.4-inch | ZC9USCL1 | PFXZC9USCL1 | USB (Type A) Cable clamp for 1 port products to prevent disconnection (5 clamps/ set) |
| USB Clamp TypeA | PFXZCBCLUSA1 | Clamp to prevent disconnection of USB cable (1 port, 5 pcs/set) | ||
| USB Clamp Type mini-B (1port) | ZC9USCLMB1 | PFXZC9USCLMB1 | Clamp to prevent disconnection of USB cable (1 port, 5 pcs/set) | |
| 3.4-inch COM I/F Connector | ZC9CMC1 | PFXZC9CMC1 | Connector for Serial I/F (1 piece) *10 | |
| Display Installation Nut | PFXZGMNT1 | Nut to install the display module (10 pcs/set) | ||
| Socket Wrench | PFXZGMSW1 | Socket wrench to tighten and loosen the display installation nut (1 pc/set) | ||
| 3.4-inch DC Power Supply Connector |
For 3.4-inch | ZCACNDCS1 | PFXZCACNDCS1 | Connector for attaching power supply to 3.4-inch GP units. (Set of 5 connectors) *11 |
| DC Power Supply Connector | For GP-4201TM/GP- 4301TM |
PFXZGMCNDC1 | Connector to connect DC power supply cables (5 pcs/set) | |
| DC Power Supply Connector (Straight type) | PFXZCBCNDC1 | Connector to connect DC powe rsupply cables (Straight type, 5pcs/set) | ||
| DC Power Supply Connector (Angle type) | PFXZCBCNDC2 | Right-angle connector to connect DC power supply cables (Angle type, 5pcs/set) | ||
| Replacement Battery | PFXZCBBT1 | Primary battery for replacement | ||
| Accessories Kit | PFXZGMAK1 | Anti-rotation Tee, USB cable clamp to prevent disconnection (USB Type A, Mini B, for 1 port), 2mm-hight spacer to adjust installation panel thickness (1pc/each |
||
เอกสาร
Related Products
Pro-face Series GP4000 Touch Screen HMI - 10.4 in, TFT LCD Display, 640 x 480pixels
PFXGP4501TADW-Pro
THB27,500.00
PFXGP4301TADW-Pro, Touchscreen Pro-face GP4000 Series Graphic Display Panel
PFXGP4301TADW-Pro
THB0.00
