| Operating Ambient Temperature | -20℃ - +50℃ |
|---|---|
| Operating Humidity Range | 90% RH or less, no condensation |
| Storage Temperature Range | -30℃ - +60℃ |
| Storage Humidity Range | 90% RH or less, no condensation |
| Mounting Location | Indoor Use |
| Mounting Direction | Upright Position |
| Protection Rating | IP65(IEC 60529) / NEMA TYPE 4X, 13 |
| Environmental Conditions | Upright Position |
| Insulation Resistance | More than 1MΩ at DC500V between the power input lead and chassis |
| Withstand Voltage | AC 500V for 1 minute between terminals and chassis without breaking insulation (M2: AC1500V for 1 min.) |
| Transistor Output | NPN / PNP (AC100 - 240V is NPN only) |
| Conformity Standards | - UL 508, CSA-C22.2 No.14 - FCC Part 15 Subpart B Class A - RoHS Directive (EN 50581) - EMC Directive (EN 61000-6-4, EN 61000-6-2) |
:
:
