RELAY BARRIER Idec, EB3C-T16CKDN, 24 VDC, DIN Rail;Panel Mounting Mount, Intrinsically Safe Relay
EB3C-T16CKDN
เอกสาร
THB0.00 THB16,800.00
จัดส่งภายใน 2–5 วัน
รายละเอียดสินค้า
| Manufacturer | Idec |
|---|---|
| Voltage | 24 VDC |
| Environment Location | Class I;II;III;Div 1 Group A;B;C;D;E;F;and G Class I;Zone 0;Exia II C |
| Number of Channels | 16 |
| Type | Intrinsically Safe Relay |
| Mounting Method | DIN Rail;Panel Mounting |
| Wire Size | 14-20 |
| Series | EB3C |
ข้อมูลสินค้า
EB3C Relay BarrierIntrinsically Safe Relay Barriers are essential components of intrinsically safe applications. These devices limit current, voltage, & total energy delivered to a sensor or any other actuator instrument located in a hazardous area. When used in areas with hazardous chemicals, gases or other ignitable atmospheres, limiting the energy is required to prevent any possible fires & explosions from occurring. Dry contact switches can be connected to the EB3C. Illuminated switches also can be connected with the combination of the EB3S Relay and the EB3L Lamp Barriers. |
 |
Key Features:
-
Zone 0 /Class I Division 1 locations
-
IEC60079 compliant
-
Dry-contact switches with 0.5Ω maximum contact resistance can be connected to the EB3C
-
8- and 16-circuit types are available in common wiring types
-
Ideal for connection to PLCs
-
Universal AC power voltage (100 to 240V AC)
-
No grounding required
-
IDEC’s original spring-up terminals minimizes wiring time
-
Installation: 35-mm-wide DIN rail mounting or direct panel mounting
-
Global usage USA: FM Canada: CSA Europe: CE marking, ATEX
|
